ERSA ANALOG 60 Lötstation 60W

Catalog no.: 0ANA60 GTIN: 4003008054866 Availability: available from stock
1 pcs.182,30

incl. VAT

zzgl. Versandkosten

ERSA ANALOG 60

The basic soldering station with industry proven technology
The station consists of:
– Electronic Station (0ANA603)
– Basic soldering iron tool 60w 60 (0670CDJ)
– 2.2 mm chisel-shaped tip ERSADUR (0832CDLF)
– Tool stand soldering iron (0A41)

The electronically temperature controlled soldering station ERSA ANALOG 60 is the base model of Lötstationenserie of ERSA. High heating power of 190 watts ensures fast up and recovery. The ceramic PTC heater takes in ERSA RESISTRONIC temperature control technique the operation of the temperature sensor. The adjustable control allows precise adjustment of the internally heated soldering tips ERSADUR with twist. The tip is connected to the high impedance front-installed earth contact. The multifunctional soldering iron stand with sponge container also serves as a tip holder.

Digital display

No

Dimensions 330 × 220 × 110 mm
Heating time

60.00 sec.

Max. solder temperature

450 °C

Temperature range

150-450 °C

anitstatic design

No

max. power

60 Watt

replacement (de-)solderiron

0670CDJ

replacement heater

067100J

soldering-/desoldering tip

0832CDLF

soldering-tip diameter / width

2.20 mm

tip series

832
