GALLUNOPTIMAL by FELDER ISO-Tin Sn100Ni+ GOSZDNi+ – Triangular rod approx. 10×10×395 mm (approx. 147 g) – Lead-free electronic solder – Price per kg
– Alloy: Sn99.25Cu0.7Ni0.05 (Ni/Ge microalloyed)
– Standard: DIN EN ISO 9453:2014
– Shape: Triangular rod, approx. 10×10×395 mm
– Weight per rod: approx. 147 g (varies depending on production)
– Melting range: 227°C (eutectic)
– Recommended wave soldering temperature: ≥ 265 °C
– Processes: wave, selective, dip soldering
– Properties: lead-free, RoHS-compliant
– Price: per kg
Sn100Ni+ as a triangular rod GOSZDNi+ combines defined process control with convenient handling. The eutectic alloy Sn99.25Cu0.7Ni0.05 (DIN EN ISO 9453:2014) melts at 227 °C and impresses with good wetting and reduced metal dissolution. The bar dimensions of approx. 10×10×395 mm and the average unit weight of approx. 147 g facilitate dosing during re-alloying. Suitable for wave, selective, and dip soldering; soldering wave temperatures of ≥ 265 °C are recommended. Billed per kilogram. Note: Individual weights may vary due to production.
